KG Series-Wet Dry Ore Sorting Machines
- Widely applicable to sorting of non-metallic and metallic ores.
- Can effectivly sort ore materials whether wet or dry, with sizes ranging from 1-5cm with the Wet Dry Ore Sorting Machines.
- The new structure solves the problem of mutual adhesion between ore and belt in the process of wet ore precessing.
- optional Deep learning module.
Tech Specs
MODEL KG5/P KGS5/P Structure Type Belt Type Belt Type Layers Single Double Capacity (t/hr) 10-40 mm | 6-10
30-50 mm | 8-13
10-40 mm | 7-12
30-50 mm | 9-15
Carryover Ratio (Bad:Good) >15:1 >15:1 Accuracy (%) >99 >99 Voltage/Frequency (V/Hz) 380/50 380/50 Power (kW) 8.4 16 Air Pressure (Mpa) 0.6~0.8 0.6~0.8 Air Consumption (M3/Min) >6 >12 Weight (Kg) 1500 2830 Dimensions (mm L*W*H) 3682*2183*1463 3777*2183*2280 Note: Parameters listed are for reference only and may vary depending on the application and feed conditions.
